Live Stream Studio Construction Costs in Klang Valley

1. Location And Fit-Out Tenure In Klang Valley

Rental is the anchor number. In 2025, light industrial units in Puchong (Bandar Bukit Puchong, Puchong Utama) sit at RM1.80–RM2.50 psf per month on three-to-five-year leases, while Balakong and Sungai Chua industrial lots run RM1.50–RM2.00 psf. Kota Damansara first-floor shop offices ask RM4.50–RM6.00 psf, and that premium rarely pays off for a project space because buyers and stream talents don’t need walk-in foot traffic.

Standard studio tenancy here is 3+2: three years fixed with a two-year renewal option. Industrial landlords in the Klang Valley typically collect two months’ deposit plus one month advance, then grant one to two months of rent-free fit-out for a 1,500 sq ft unit. The renting clause matters — insist it is written as “light assembly and broadcasting studio (non-public access)”. Several landlords in Puchong enforce a floor loading cap of roughly 100 kg/m² for non-partitioned warehouse slabs. That cap does not bite on a lightweight 300 mm stage riser, but it does rule out a 3-ton immovable set with concrete columns. Get the clause in writing before paying the deposit.

2. Acoustic Isolation And Interior Build-Out Costs

Bare concrete units in this market need everything. A&R (alteration and renovation) runs RM18–RM28 psf for the base package: gypsum board partitioning with rockwool infill, full painting, LED bulkheads, and CAT6 cable trays. On 1,500 sq ft that is RM27,000–RM42,000 from the kind of fit-out contractors who quote on industrial units in Shah Alam and Balakong.

Acoustic treatment is a separate line. Polyester fibre matrix panels installed by Klang Valley acoustic subcontractors cost RM12–RM24 psf. A full wrap of a 600 sq ft broadcast set area, including the control room wall, lands at RM7,200–RM14,400. Solid-core acoustic doors with perimeter seals cost RM1,800–RM2,800 per unit installed, so a control room plus two entry points totals RM5,400–RM8,400. If you want a sightline window between the set and the control room, a fixed double-glazed laminated 10 mm pane runs RM1,200–RM1,600 per square metre installed. Skimp on the door seals first, not on the wall infill — the flanking path through a cheap door will undo 30% of your wall budget.

3. Camera, Audio And Streaming Stack Cabling

The single largest line item in any Klang Valley build is the capture and streaming stack, and it is usually quoted by AV integrators in PJ’s digital mall district rather than the A&R contractor. A reliable four-camera path starts at three Panasonic Lumix GH6 bodies (RM7,900 each) with 24–105 mm f/4 lenses (RM6,800), or the Sony FX3 plus 24–70 mm f/2.8 if the studio will be rented out for branded livestreams (RM13,500 + RM7,800 respectively). Truss-mounted PTZ units from PTZOptics run RM8,000–RM12,000 per camera and cut operator labour on standard e-commerce shoots.

The switching room needs a Blackmagic ATEM Mini Pro ISO (RM2,600) for a compact rig, or an ATEM Constellation 2 M/E for multi-room talk shows. Audio stays Shure SM7B microphones (RM2,100 each) into a Rodecaster Pro II (RM3,300), with a Sennheiser EW-D wireless lav kit (RM3,500) for guest segments.

The real cost surprise is the dual-PC rack. A capture PC and a streaming PC, each built around an Intel Core i7-14700K, RTX 4070 Ti Super and 64 GB RAM, come to RM12,000–RM16,000 per unit at current KL GPU pricing. That is RM24,000–RM32,000 just for encoding and Camera Control software. SDI and fibre-optic camera runs from the set to the rack add RM800–RM1,500 per cable line installed, including termination and label plates.

4. Fibre, 5G Failover And Power Capacity

Construction cost includes the uplink path. Primary WAN for a Puchong or Kota Damansara unit is TIME Fibre Business at 1Gbps symmetrical for RM299–RM399 per month — but only where TIME coverage actually exists on that street; many industrial lots in Balakong are Unifi-only. Unifi Business 1Gbps is RM399 with the option of a static IP. The overhead nobody budgets for is the failover leg: a Maxis Business 5G fixed-wireless router on an RM159 plan or a CelcomDigi business 5G SIM in a router with dual-WAN capability. After dual-WAN is up, the metric that matters is packet loss below 0.02% and jitter under 2 ms on the primary route.

Power is the other hidden charge. Most industrial units run a 63A single-phase supply, which is not enough for a 4× 2HP inverter air-conditioning bank (RM2,000–RM2,800 each installed), ten LED key lights, and two 700 W render stations. The 3-phase 100A upgrade application through Tenaga Nasional and a Suruhanjaya Tenaga-registered contractor costs RM2,500–RM6,000 in connection and wiring work. If you skip the upgrade and run lights and PCs on extension coils from different breakers, you will trip a 63A incoming breaker mid-stream during the second hour of load. That is the most common cause of a dead broadcast here.

5. Total Budget Benchmarks For A 1,500 Sq Ft Studio

For a modest e-commerce corporate studio in Puchong — bare unit, one set, four-mirrorless camera path, and no PTZ robotics — the realistic full construction figure is RM118,000–RM145,000. The breakdown: RM15,500 rental deposit plus RM35,000 A&R, RM22,000 acoustic isolation, RM42,000 camera/audio/switcher and rack PCs, and RM19,000 network, power and air-conditioning.

The premium tier — a multistream talk-show room with three PTZ heads, an LED wall segment, double-glazed control window and 3-phase upgrade — pushes the same shell to RM190,000–RM231,000. Recurring operating cost outside payroll is RM4,800–RM7,000 per month: RM2,700–RM4,500 in rent, RM500–RM900 in electricity at the 2025 non-domestic low-voltage tariff, RM400–RM600 in dual-WAN internet, and RM150 for AC servicing.
